AI BOX RZ/V ( RZ/V2H )
Part No. RZ/V2H
MPU family for embedded Vision AI applications
Integrates Renesas original AI accelerator DRP-AI(*1) to deliver up to 80TOPS
Delivers AI power efficiency up to 10TOPS/W
Provides AI performance scalability for wide range of applications
Specifications
CPU: 4x Cortex-A55 @ 1.8GHz (O/D*); 2x Cortex-R8 @ 800MHz; Cortex-M33 @ 200MHz
DRAM I/F: 32bit x2ch LPDDR4/4X(3200)
Video In: Support up to 4K 30fps @1 camera; Up to 4 camera input; 2x MIPI-CSI2 4lane
Video Codec: Encoding and Decoding: H.265, H.264 (up to 4K 30fps)
Camera ISP: Yes (Dedicated H/W)
AI Accelerator: DRP-AI3 (ResNet-50: 830fps)
GFX: 3D Graphics (Arm Mali-G31)
Vision/Dynamics Accelerator: OpenCV accelerator (DRP)
Display Out: MIPI-DSI x1
USB: USB3 (Gen2x1) host x2; USB2.0 host/func x1, host x1
Gbit Ethernet: 2ch (with PTP)
PCIe: Gen3 (x4 x1 or x2 x2)
CAN: CAN-FD / CAN 6ch
SD/MMC: SD x3ch, MMC x1ch
Audio: SSI(I2S) TDM x10, SPDIF x3; ASRC, PDM input x6
Package: FCBGA, 19mm x 19mm (0.5mm pitch)
OS: Linux on CA55, FreeRTOS on CR8, CM33
Download attachment
| File name | File Description | |
|---|---|---|
| OneKiwi_v2h_Vision_AI_Box_Full_Datasheet_V3-1.pdf | Data Sheet |
