SN8F5708
8-bit architecture microcontroller, from 1.8 V to 5.5 V, -40°C and 85°C at 32 MHz CPU clock rate.
16 KB flash memory (IROM), 256 bytes internal RAM (IRAM) and 1 KB on-chip external RAM (XRAM).
12 input channels/12-bit resolution ADC, 2-set of OP-Amps and 2-set comparators, three PWM generators, interfaces (UART, SPI, I2C) and 16-bit timers
Specifications
Timers
Int. Flash (KB)
16
SRAM (KB)
256 bytes
Communication
I²C
1
Analog
12-bit ADC numbers/channels
12
Comparators
2
GPIO
-
Operating temperatures
-40°C ~ 85°C
Specifications
Package
LQFP48,QFN48
Max Operating Frequency (Mhz)
32
SPI
1
UART
1
