High Voltage Ceiling Fan ( HV48V )
Part No. iU6399 + iT62248
"Household Fan Household Fan
Air Purifier Air Purifier
Dehumidifier Fan
Sweep Robot Sweep Robot
RO Water Purifier RO Water Purifier "
"Indoor/Outdoor (IDU/ODU) Indoor/Outdoor (IDU/ODU)
Air Condiction Fan Air Condiction Fan
Freezer Fans Freezer Fans
Bathroom Exhaust Fan Bathroom Exhaust Fan
High Speed Hair Dryer High Speed Hair Dryer "
Main advantages
- Unique FOC control technology to implement Silence Operation
- Adaptive Algorithm FOC automatically optimizes efficiency under different coil deviation
- Constant speed under different fan loading
- Built-in Protection
- Ease to Use Parameter Modification Platform
- 4-Wire Programming"
Specifications
3-Phase FOC Controller with P/N Pre-Driver
Operation Voltage 7V-32V
Embedded with : 5V LDO, Current Amplifierx2, 40V P/N Pre-driver
Low power stop mode
Control Functions: support PWM duty/ DC/ Clock unput; Adjustable PWM Frequency; Lead angle; FG Output; Adjistable Start
Built-in Protection: Over-Voltage; Over-Temperature; Over-Current; Auto Recovery
