Solar Device Test Equipment Four-Station TMTT Photovoltaic Test System
Part No. TS100JA
Specifically designed for solar panel bypass diodes
Simultaneous measurement key parameters including VF, VBR, and IR.
Supports advanced test items:
IR Surge, VB,
ΔVR, IR%, IR1, IR2, and DIR.
Automatic polarity detection.
Suitable for production testing, incoming/outgoing inspection, R&D, and sample evaluation.
Compatible with switch boxes for solar module electrical testing.
Specifications
Multi-Function Diode Sorting Tester
DC TESTER
Voltage Output: 1V - 400V
Current Measurement: 1nA - 10MA
Current Output: 1uA - 100A
Voltage Measurement: 1 mV - 400V
