Solar Device Test Equipment Four-Station TMTT Photovoltaic Test System
Part No. SSG6050
Dedicated to reverse surge testing of Schottky diodes
Used to evaluate the reliability of guard ring structures
Supports multiple package types with 11 built-in package selections
Automatic polarity detection
Compatible with TMTT handler
Specifications
SCHOTTKY DIODE REVERSE SURGE TESTER
Current Output: 0.5A - 50V
Voltage Measurement: 5V - 350V
PULSE WIDTH: 1 μS ~ 100 μS
PERIOD: 100 μS ~ 9999 μS
PULSE NO: 1~ 20
Related Application
